Pro Max mobile phone signal booster to improve calls and 4G 5G data services

(20 customer reviews)

AU$395.00

Filters Sort results
Reset Apply
Key Features
Application
Frequency Bands
700
MHz
(Band
28
)
Coverage
up to 150m²
Ideal for
⋅
Providers & Services Supported
A Standard Kit includes
1x Booster + Power Adapter
1x Indoor Ceiling Antenna
1x Outdoor High Gain LPDA Antenna
1x 15-meter Ultra Low Loss Cable
1x 5-meter Ultra Low Loss Cable
2-Year Warranty
30-Day Money Back
Upgrade outdoor antenna | Easier installation
None omni-directional antenna +AU$90.00
Need Extra internal antenna(s) ?
None 1x ceiling antenna (omni-directional) +AU$25.00 1x panel antenna (directional) +AU$35.00 2x ceiling antennas (omni-directional) +AU$45.00 1x ceiling antenna + 1x panel antenna +AU$55.00 2x panel antennas (directional) +AU$65.00

  • Safe And Secure Shopping
  • Delivery Time 5-7 Business Days. Trackable Delivery.
  • 30-Day Money-Back Guarantee
  • Price Match Guarantee
  • sales@hanphoenix.com

Description

Filters Sort results
Reset Apply
Our Pro Max mobile signal booster is an ideal solution for weak outside sgnal condtions for rural and urban areas with faulty reception. This powerful and robust device will enhance mobile signal on 4G, 5G network freuqency at flats, cafes, bars, small hotels, large houses, and restaurants, all over the country. The installation kit contains all the necessary elements to set up your booster quickly and effectively, so you, your family, colleagues or clients can benefit from a full 5-bar connection anytime.
This booster works with
The Booster also supports Mobile Virtual Network Operators (MVNOs) associated with the supported host network operators.
All MVNOs in Australia lease services from three major host networks: Telstra, Optus, and Vodafone. The detailed associated MVNOs for each host network are as follows.
What makes our boosters different?
1. Equipped with an advanced DSP for high-efficiency signal processing.2. Delivers radio spectrum performance that surpasses industry standards.3. Features a unique intelligent decision-making system that adapts in real time to on-site signal strength, creating professional-grade signal boosters with exceptional reliability.
5-level signal filtering effectively eliminates noise and out-of-band emissions, preventing interference to cellular base stations.
1. RADIO EMC EMF SAFETY tests verify no harm to human health and no interference to cell stations.2. Radio Equipment Directiive CE certified. Ofcom Exemption.
Automatic standby mode when idle, energy-efficient and long-lasting performance.
How to install the booster kit?
1. Find a strong outdoor signal sourceChoose an open area outside your property, preferably at a higher elevation (e.g., rooftop). Place the outdoor antenna by type:A - Directional antennas (LPDA, Yagi, Panel): Point directly toward the cell tower, with no obstacles nearby.B - Omni-directional antenna (Pipe antenna): Point vertically toward the sky, with no obstacles nearby (cell tower direction is irrelevant).2. Connect the outdoor antennaUse the 15-meter cable (or sufficient length) to connect the outdoor antenna to the “Outdoor ANT” port on the booster.3. Place and connect the indoor antennaPosition the indoor antenna in the central area of the target coverage zone, keeping it clear of obstacles. Use the 5-meter cable (or sufficient length) to connect it to the “Indoor ANT” port on the booster.4. Power on the booster. Check the LED indicators on the booster to confirm normal operation (refer to LED State Explanation below).
Easy to understand booster working status
Power LED
Green – Power ON (normal)
Dark - No power supply
Down Link LED (DL/P) - Signal Amplification Status
Dark - No signal received
Blue - Weak signal received, working.
Green - Good working state
Bright Red - Optimal working state.
Up Link LED (UL/P) - Calling & Alarm Status
Dark - No calls, standby state
Flicker - Calls/internet active, working state
Solid Red - Alarm, check installation.
What to do in ALARM state - Turn off the booster, check installation per the troubleshooting section in the full user manual. The booster will resume normal operation automatically after the issue is resolved.
Technical Specifications
Frequency Bands
Band
28
Linear Gain (UL/DL)
Upon outside signal conditions
Output Signal Power
Upon coverage
ALC/AGC Range
≥ 20dB
MGC Adjustment Range (optional)
Max 31dB in step of 1dB
Noise Figure @ Full Gain
≤ 6dB
In Band Ripple
≤ 5dB
Group Delay
≤ 5μs
VSWR
≤ 1.8dB
Spurious Emission
9KHz ~1GHz ≤ -36dBm/100KHz1GHz ~12.5GHz ≤ -30dBm/1MHz
Inter-modulation
≤ -40dBc
Return loss
≤- 8 dB
Max. Input Power Without Damage
0 dBm
Frequency Stability
≤0.01ppm
MTBF
>50000 hours
System Impedance
50Ω
AC Power Requirements
100 ~ 240VAC / 45 ~ 65Hz
CE certification
RED CE
